Bi Directional Automotive TVS Diode SM8S28CAG Low Leakage Current DO-218AB

Brand Name : SOCAY

Model Number : SM8S28CAG

Certification : UL,REACH,RoHS,ISO

Place of Origin : Shenzhen, Guangdong, China

MOQ : 500PCS

Price : Negotiable

Delivery Time : 1-3weeks

Item : Diodes for Automotive

Package size : DO-218AB

Vr : 28V

Ir@Vr @25℃ : 5μA

Ir@Vr @175℃ : 150μA

Vbr@It (Min.) : 31.1V

Vbr@It (Max.) : 34.4V

It : 5mA

Vc@Ipp : 45.4V

Ipp : 145A

Contact Now

Bi-Directional TVS SM8S28CAG Transient Voltage Suppressors, Low Leakage Current

DATASHEET: SM8SXXG Series_v2309.1.pdf

Bi Directional Automotive TVS Diode SM8S28CAG Low Leakage Current DO-218AB

Description:

TVS tubes are widely used for the protection of semiconductors and sensitive devices, usually for diode protection. They are characterised by their fast response time (PS level), small size, high transient pulse suppression power and low clamping voltag

Material

Semiconductor materials, die, resin packages

Function

It's use for AUTOMOTIVE Circuit Protection

Part Number

Working Peak

Reverse

Voltage VRWM

(V)

Breakdown

Voltage

VBR (V)

Test Current

IT

(mA)

Maximum Reverse Leakage IR @ VRWM

(µA)

Maximum

IR @ VRWM TJ=175℃

(µA)

Maximum Reverse Surge Current

IPP (A) ①

Maximum Clamping Voltage

VC @ IPP

(V)
Uni Bi Min. Max.
SM8S28AG SM8S28CAG 28.0 31.1 34.4 5.0 10 150 145 45.4

Notes:

1. Surge current waveform is defined at 10/1000μS waveform.

2. For all types maximum VF = 1.8 V at IF = 100 A measured on 8.3 ms single half sine-wave or equivalent square wave, duty cycle = 4 pulses per

minute maximum.

Application:

Traffic recorder
ADAS Advanced Driver Assistance System
OBD vehicle diagnostic system
DMS Driver condition monitoring Department
Car LED
Cigarette lighter
Car audio
